| 产品编号 NO.of product | 沟槽尺寸（dimension of slot） | O型圈（O-type ring） GB3452.1-1992 d1×d2 | ||||||
| d内径 inner diameter/ID | D外径 outer diameter/OD | B壁厚 wall thickness | L高度 height | Rmax | E直径间隙（diameter gap） | |||
| 0-20MPa | 20-20MPa | |||||||
| JD-25-8 | 8 | 15.5 | 3.75 | 3.2 | 0.5 | 0.6-0.3 | 0.3-0.1 | 10.6×2.65 |
| JD-25-10 | 10 | 17.5 | 12.5×2.65 | |||||
| JD-25-12 | 12 | 19.5 | 14×2.65 | |||||
| JD-25-14 | 14 | 21.5 | 16×2.65 | |||||
| JD-25-16 | 16 | 23.5 | 19×2.65 | |||||
| JD-25-18 | 18 | 25.5 | 20×2.65 | |||||
| JD-25-20 | 20 | 31 | 5.5 | 4.2 | 0.7 | 0.6-0.3 | 0.3-0.2 | 23.6×3.55 |
| JD-25-22 | 22 | 33 | 26.5×3.55 | |||||
| JD-25-25 | 25 | 36 | 28×3.55 | |||||
| JD-25-28 | 28 | 39 | 31.5×3.55 | |||||
| JD-25-30 | 30 | 41 | 34.5×3.55 | |||||
| JD-25-32 | 32 | 43 | 36.5×3.55 | |||||
| JD-25-35 | 35 | 46 | 37.5×3.55 | |||||
| JD-25-36 | 36 | 47 | 41.2×3.55 | |||||
| JD-25-40 | 40 | 55.5 | 7.75 | 6.3 | 1.2 | 0.8-0.4 | 0.4-0.2 | 43.7×5.3 |
| JD-25-45 | 45 | 60.5 | 50×5.3 | |||||
| JD-25-50 | 50 | 65.5 | 53×5.3 | |||||
| JD-25-55 | 55 | 70.5 | 58×5.3 | |||||
| JD-25-60 | 60 | 75.5 | 63×5.3 | |||||
| JD-25-63 | 63 | 78.5 | 67×5.3 | |||||
| JD-25-65 | 65 | 80.5 | 69×5.3 | |||||
| JD-25-70 | 70 | 85.5 | 75×5.3 | |||||
| JD-25-75 | 75 | 90.5 | 80×5.3 | |||||
| JD-25-80 | 80 | 95.5 | 85×5.3 | |||||
| JD-25-85 | 85 | 100.5 | 90×5.3 | |||||
| JD-25-90 | 90 | 105.5 | 95×5.3 | |||||
| JD-25-95 | 95 | 110.5 | 100×5.3 | |||||
| JD-25-100 | 100 | 115.5 | 106×5.3 | |||||
| JD-25-105 | 105 | 120.5 | 109×5.3 | |||||
| JD-25-110 | 110 | 125.5 | 112×5.3 | |||||
| JD-25-120 | 120 | 135.5 | 122×5.3 | |||||
| JD-25-125 | 125 | 140.5 | 128×5.3 | |||||
| JD-25-130 | 130 | 145.5 | 132×5.3 | |||||
| JD-25-140 | 140 | 155.5 | 145×5.3 | |||||
| JD-25-150 | 150 | 165.5 | 155×5.3 | |||||
| JD-25-160 | 160 | 175.5 | 165×5.3 | |||||
| JD-25-180 | 180 | 195.5 | 185×5.3 | |||||
| JD-25-200 | 200 | 221 | 10.5 | 8.1 | 1.5 | 1.0-0.6 | 0.6-0.4 | 206×7 |
